PURPOSE BUILT FOR CONTINUOUS OPERATION

PhoeniX IDU G2+

Split mount / full indoor modem with dual-core XPIC, embedded interfaces and fanless reliability for backbone deployments

Highlights & benefits

Key characteristics

PhoeniX IDU G2+

Customizable configuration in a single chassis design

PhoeniX IDU G2+ is an integrated, high-capacity microwave platform built for critical infrastructure. It offers embedded ASI and E1/T1 options, a fanless design, and a touch-sensitive LCD for local control - ideal for high availability broadcast and utility applications.

With up to 1.8 Gbps throughput and full system redundancy, IDU G2+ delivers secure, reliable performance with advanced monitoring and simplified operation in a single 2U chassis.

High Capacity Throughput

Market-proven technology with support for 2048 QAM modulation and 112 MHz channel bandwidth delivers high-throughput capacity - up to 712 Mbps per radio.

Flexible Network Configuration

With a single IDU supporting one or two ODUs, PhoeniX IDU G2+ enables flexible deployment options including 1+0, 2+0 with Layer 1 aggregation, and 1+1 link protection in HSB, FD, or SD modes, as well as 2+0 XPIC configuration. For ultra-reliable link requirements, PhoeniX IDU G2+ offers Full Redundancy with a dual IDU setup, supporting 1+1 and 2+2 configurations - ensuring redundancy across all active components for maximum link availability.

Excellent for Network Upgrade

The flexible TDM/IP architecture of the PhoeniX series enables a seamless transition from TDM-only to hybrid or full IP networks, all within a single, highly configurable device. With optional expansion modules, it supports up to 64×E1 or 16×ASI streams, and includes built-in STM-1/OC-3 support for enhanced scalability and integration.

Enhanced Ethernet Functionality

The built-in managed Gigabit Ethernet switch supports QoS, VLANs with QinQ, transparent IEEE 1588v2, and AES-256 over-the-air encryption, along with other essential features - enabling the setup and maintenance of highly customized end-user connectivity services.

Key characteristics

PhoeniX IDU G2+

PhoeniX IDU G2+ Advanced

Capacity

up to 1.2 Gbps*

up to 1.8 Gbps*

Frequency bands

2, 4, 6, 7, 8, 11, 13, 15, 18, 23, 26 and 38 GHz

2, 4, 6, 7, 8, 11, 13, 15, 18, 23, 26 and 38 GHz

Modulation

up to 1024QAM

up to 2048QAM

Channel bandwidth

ETSI

3.5 MHz - 56 MHz

1.75 MHz - 112 MHz

FCC

5 MHz - 80 MHz

2.5 MHz - 100 MHz

Configurations

1+0, 1+1 HSB/SD/FD, 1+0 Dual, 1+0 Star (Repeater), 2+0 (Layer 1 aggregation),
2+0 XPIC, 2+2 aggregation/protection (with two IDUs)

Ports

RJ-45

3 x RJ-45 (10/100/1000 Base-T)

3 x RJ-45 (10/100/1000 Base-T)

SFP

4 x SFP (1000 Base-SX/LX)

4 x SFP (1000 Base-SX/LX)

Alarm

–

B08-XASK-1 (2 x Alarm In, 2 x Alarm Out)

STM-1/OC-3

–

up to 2 x STM-1/OC-3 optical interfaces

Power

2 x DC

2 x DC

Form factor

Size

19" 2U (90 x 430 x 265 mm / 3.54 x 16.93 x 10.43 in)

Weight

<5.3 kg / 11.7 lb

Power consumption

IDU only

<27W

4 x ASI

<10W

16 x E1/T1

<10W

* in 2+0 configuration
