MODULARITY WITHOUT COMPROMISE

PhoeniX G2

Modular split-mount / full-indoor modem with flexible expansion, native IP/ASI/TDM transport, and carrier-grade performance

Highlights & Benefits

Key Characteristics

PhoeniX G2

Mission-critical, high capacity backhaul

PhoeniX G2 is a modular microwave platform designed for carrier-grade performance and seamless hybrid network evolution. With support for up to 1.4 Gbps throughput, advanced 2048QAM modulation, and native IP, ASI, and TDM transport, it delivers the high capacity and flexibility needed for telecom, broadcast, and utility backhaul.

Designed for mission-critical deployments, the Phoenix G2 offers redundant configurations, AES-256 encryption, and advanced remote management. Its modular architecture enables flexible expansion with external ASI and E1/T1 interfaces, ensuring long-term scalability and reliability.

High Capacity Throughput

Market-proven technology with support for 2048QAM modulation and 112 MHz channel bandwidth delivers high-throughput capacity - up to 712 Mbps per radio.

Flexible Network Configuration

With a single IDU supporting one or two ODUs, PhoeniX G2 enables flexible deployment options including 1+0, 2+0 with Layer 1 aggregation, and 1+1 link protection in HSB, FD, or SD modes, as well as 2+0 XPIC configuration. For ultra-reliable link requirements, PhoeniX G2 offers Full Redundancy with a dual IDU setup, supporting 1+1 and 2+2 configurations - ensuring redundancy across all active components for maximum link availability.

Excellent for Network Upgrade

The flexible TDM/IP architecture of the PhoeniX Series enables a seamless transition from TDM-only to hybrid or full IP networks, all within a single, highly configurable device. With optional expansion modules, it supports up to 64×E1 or 16×ASI streams, and includes built-in STM-1/OC-3 support for enhanced scalability and integration.

Enhanced Ethernet Functionality

The built-in managed Gigabit Ethernet switch supports QoS, VLANs with QinQ, transparent IEEE 1588v2, and AES-256 over-the-air encryption, along with other essential features - enabling the setup and maintenance of highly customized end-user connectivity services.

Key Characteristics

PhoeniX G2

PhoeniX G2 Advanced

Capacity

up to 1.2 Gbps*

up to 1.4 Gbps*

Frequency bands

2, 4, 6, 7, 8, 11, 13, 15, 18, 23, 26 and 38 GHz

2, 4, 6, 7, 8, 11, 13, 15, 18, 23, 26 and 38 GHz

Max. modulation

1024QAM

2048QAM

Channel bandwidth

ETSI

3.5 MHz - 56 MHz

1.75 MHz - 112 MHz

FCC

5 MHz - 80 MHz

2.5 MHz - 100 MHz

Configurations

1+0, 1+1 HSB/SD/FD, 1+0 Dual, 1+0 Star (Repeater), 2+0 (Layer 1 aggregation),
2+0 XPIC, 2+2 aggregation/protection (with two IDUs)

Ports

RJ-45

3 x RJ-45 (10/100/1000 Base-T)

3 x RJ-45 (10/100/1000 Base-T)

SFP

4 x SFP (1000 Base-SX/LX)

4 x SFP (1000 Base-SX/LX)

Alarm

–

B08-XASK-1 (2 x Alarm In, 2 x Alarm Out)

STM-1/OC-3

–

up to 2 x STM-1/OC-3 optical interfaces

Power

1 x DC power port

2 x DC power ports

Form factor

Size

1/2 width 1U (44 x 220 x 240 mm / 1.73 x 8.66 x 9.45 in)

Weight

2.2 kg / 4.9 lb

Power consumption

IDU only

<30W

* in 2+0 configuration

Download product brochure

Industries we serve

Finance and Trading

Our solutions help financial institutions and trading platforms execute transactions quickly and reliably. In this sector, every nanosecond matters, and we ensure leading performance.

Government and Defense

We offer secure communication systems that are essential for defense and surveillance operations. Our technology supports critical infrastructure with real-time, low-latency data transmission.

Energy and Utilities

We enable real-time data monitoring in smart grids and pipelines. Our solutions also support fast telemetry and SCADA system communications, ensuring efficient and reliable operations.

Broadcasting

We enable high-speed video and audio transmissions, making our solutions ideal for live broadcasting. Our technology also supports remote production workflows, ensuring minimal latency in real-time operations.

Downloads

Looking for detailed specs, configuration options, or use-case insights? Download the latest product documents to support your planning and deployment.

Go to downloads
